CARTRIDGE POOL FILTER INSTALLATION ECO WISE 4 FOR POOLS UP TO 85,000L

Product Description

The BADU Eco Wise 4 Cartridge Filter Installation is a complete supply and installation service for pool owners in Gauteng East who need a cartridge pool filter replacement for a residential pool or spa system. This service includes the BADU Eco Wise 4 cartridge filter, old filter removal where suitable, standard installation labour, pipework adjustments and basic testing after installation.

The BADU Eco Wise 4 is designed for an average pool size of up to 85,000 litres, with a supplied flow rate of 16m³/h at 350kPa. It can be used with 1.05kW, 1.1kW and 1.2kW pool pumps, depending on the full system layout, pipework condition, debris load and circulation requirements.

As a cartridge filter, the BADU Eco Wise 4 does not rely on regular backwashing like a sand filter. The cartridge is removed and cleaned manually, helping reduce water loss during routine filter maintenance. This makes it a practical choice for pool owners who want strong filtration with a simpler, water saving maintenance routine.

This filter is best suited to pools and spas with regular maintenance and a manageable debris load. Pools surrounded by large trees, heavy leaf fall or garden debris may require more frequent cartridge cleaning. Final suitability depends on the existing pump, pipework, plumbing layout, filter position, pool size and complete filtration setup.

This is a supply and installation package, not a supply only filter listing. The installation is based on using the existing above ground filter position where suitable, with the filter installed on a stable and suitable surface. Any extra plumbing, pump replacement, electrical work, site preparation or repairs to faulty existing infrastructure must be quoted separately before work is done.

FAQs

What is included in the BADU Eco Wise 4 cartridge filter installation?

This service includes the BADU Eco Wise 4 cartridge filter, old filter removal where suitable, standard installation labour, pipework adjustments where required, fittings where required and basic system testing after installation.

Is this a supply only product or a full installation service?

This is a full supply and installation service. The customer receives the physical cartridge filter and the standard installation work.

What pool size is the BADU Eco Wise 4 suitable for?

The supplied information states that the BADU Eco Wise 4 is designed for an average pool size of up to 85,000 litres, subject to the full system layout.

What pump sizes can be used with this filter?

The supplied information states that this filter can be used with 1.05kW, 1.1kW and 1.2kW pool pumps, depending on the full pool system setup.

What is the flow rate of the BADU Eco Wise 4?

The supplied flow rate is 16m³/h at 350kPa.

Does the BADU Eco Wise 4 require backwashing?

No. Cartridge filters do not require backwashing. The cartridge is removed, rinsed and refitted as part of routine maintenance.

How does this cartridge filter help reduce water usage?

Because it does not need backwashing, less pool water is wasted during normal filter cleaning compared with a traditional sand filter setup.

Is this filter suitable for spas?

Yes. The BADU Eco Wise cartridge filter range is suitable for pools or spas, subject to correct system sizing and plumbing layout.

Is this filter suitable for heavy leaf pools?

It can be used on suitable systems, but cartridge filters are better suited to pools with manageable debris. Heavy leaf areas may require more frequent cartridge cleaning.

Does the installation include old filter removal?

Yes. The service includes removal of the old above ground pool filter where site conditions allow safe and practical removal.

Does the installation include pipework?

Standard pipework adjustments are included where required for the filter replacement. Major plumbing changes, long pipe runs or system alterations must be quoted separately.

Does this installation include electrical work?

No. This is a filter installation service. Electrical repairs, DB board changes, timer replacement and pump wiring faults are excluded unless quoted separately.

What warranty is included?

The installation workmanship is covered by a 1 year warranty. The BADU Eco Wise filter range information supplied earlier includes a 12 month ex factory warranty under normal operating conditions.

What affects final suitability?

Final suitability depends on the existing pump, pool volume, pipework condition, filter position, debris load, cartridge maintenance routine and complete pool system layout.

Service Inclusions

This installation service includes:

Supply of the BADU Eco Wise 4 cartridge filter

Removal of the old above ground pool filter, where conditions allow

Travel within the Gauteng East service area

Standard installation labour

Standard pipework adjustments where required

Standard fittings and solvent weld where required

Connection to the existing above ground filter position where suitable

Final assembly and basic testing for leaks and operation

Basic handover on cartridge cleaning and filter care

Work Summary

The installation normally starts with a basic inspection of the existing filter setup, including the filter position, plumbing layout, visible pipe condition and available working space.

The old above ground pool filter is disconnected and removed where the site allows safe access.

The new BADU Eco Wise 4 cartridge filter is positioned in the existing filter area where suitable.

The required fittings are installed, and the filter is connected to the existing pool plumbing setup.

The cartridge filter housing is checked, the system is started, and the installation is tested for leaks, flow and basic operation.

The customer is advised that cartridge cleaning is done by removing and rinsing the cartridge, not by backwashing.

Exclusions

This standard installation does not include major plumbing changes, DB board changes, timer replacement, electrical fault repairs, waste line changes, water supply changes, long pipe runs beyond the standard allowance, pump room rebuilding, concrete work, new pump installation unless specifically included, or repairs to faulty existing infrastructure.

This service also does not include moving the filter to a new position, preparing an unsuitable surface, replacing a faulty pump, repairing old leaking pipes, correcting incorrect existing plumbing, or ongoing cartridge cleaning and maintenance unless quoted separately.

Any extra work must be quoted separately before it is done.

Terms and Conditions

This installation service is available in Gauteng East.

Installation normally takes place within 2 to 3 working days after receipt of order, depending on scheduling and site readiness.

The installation area must be cleared and ready before the team arrives.

The installation is based on using the existing above ground filter position, plumbing and pool system infrastructure, provided they are safe, suitable and in working condition.

This listing is intended for pools up to 85,000 litres using 1.05kW, 1.1kW or 1.2kW pool pumps, subject to final site suitability.

Final suitability depends on the existing pump, pipework, pool volume, debris load, cartridge maintenance routine and full system layout.

Installations on plots and farms within Gauteng may carry a surcharge.

The installation workmanship is covered by a 1 year installation workmanship warranty.

The BADU Eco Wise filter range information supplied earlier includes a 12 month ex factory warranty under normal operating conditions from date of purchase.

Technical Specifications and Compatibility

Product Details

Product Name: BADU Eco Wise 4 Cartridge Filter Installation
Brand / Range: BADU Eco Wise
Product Type: Cartridge pool filter supply and installation
Filter Type: Cartridge filter
Average Pool Size: Up to 85,000 litres
Application: Pools and spas
Installation Type: Supply and standard installation
Service Area: Gauteng East

Motor and Performance

This product is a pool filter, not a pool pump.

Flow Rate: 16m³/h at 350kPa
Compatible Pump Sizes: 1.05kW, 1.1kW and 1.2kW pool pumps
Performance Note: Final filtration performance depends on pump size, plumbing layout, cartridge condition, pool volume, debris load and full pool system setup.

Cartridge Filter Features

Cartridge Maintenance: Cartridge is removed and rinsed, with no backwashing required
Water Saving Benefit: Reduced water waste compared with backwashing based filter cleaning
Pool and Spa Use: Suitable for pools or spas, subject to correct sizing and system layout
Debris Note: Best suited to pools with regular maintenance and manageable debris load

Electrical Details

No electrical specifications are supplied for this product because it is a filter installation service.

Electrical repairs, DB board changes, timer replacement and pump electrical faults are excluded unless quoted separately.

Plumbing and Build

Filter Design: Cartridge filter casing
Connection Size: Not supplied in the provided Eco Wise 4 information
Dimensions: Not supplied in the provided Eco Wise 4 information
Installation Position: Existing above ground filter position where suitable
Installation Surface: Stable and suitable surface required
Pipework: Standard pipework adjustments where required for the replacement installation

Pool Compatibility

Pool Size Compatibility: Up to 85,000 litres
Pump Compatibility: 1.05kW, 1.1kW and 1.2kW pool pumps
Spa Compatibility: Suitable for spas, based on supplied Eco Wise range information
Pool Surface Compatibility: This product is not limited to one pool surface in the supplied information. Final suitability depends on the existing pool system and installation setup.
System Compatibility: Final suitability depends on the existing pump, plumbing, filter position, water condition, debris load and cartridge cleaning routine.

Installation Conditions

Service Area: Gauteng East
Lead Time: Normally 2 to 3 working days after receipt of order
Site Preparation: Installation area must be cleared and ready
Existing Infrastructure: Existing plumbing must be suitable and in working condition
Surcharge Note: Plots and farms within Gauteng may carry a surcharge
Installation Warranty: 1 year workmanship warranty
Product Warranty: 12 month ex factory warranty under normal operating conditions, based on the supplied Eco Wise range information

What’s in the Box

Physical Product Contents

BADU Eco Wise 4 cartridge filter

Cartridge filter housing

Cartridge element

Installation Service Contents

Old above ground filter removal where conditions allow

Professional standard installation

Standard fittings where required

Connection to existing pool plumbing where suitable

Final assembly and basic leak testing

Travel and labour within the Gauteng East service area

Basic cartridge maintenance handover

Conclusion

The BADU Eco Wise 4 Cartridge Filter Installation is a practical choice for pool owners who want cartridge based filtration for larger residential pools or spa systems. With a pool size rating of up to 85,000 litres and a supplied flow rate of 16m³/h at 350kPa, it offers a strong filtration option when correctly matched to the pump and plumbing setup.

For suitable systems using 1.05kW, 1.1kW or 1.2kW pumps, this installation provides a neat replacement solution with lower water loss during routine maintenance and clear service terms before installation starts.
